Camera tech data for Sony ILCA-77M2
| General | |
|---|---|
| Name | Sony ILCA-77M2 , α77Ⅱ, A77Ⅱ |
| Mount type | A-mount |
| Supported lenses | classic, xi, SSM, SAM, (D), DT |
| Release year | 2016 |
| Status | discontinued |
| Digital parameters | |
| Output resolution [pixels] | 6000×4000, 4240×2843, 3008×2000 |
| Output resolution (16:9) [pixels] | 6000×3376, 4240×2400, 3008×1688 |
| Output resolution (panorama) [pixels] | 12416×1856, 5536×2160, 8192×1856, 3872×2160 |
| Output resolution (3D panorama) [pixels] | – |
| Effective output pixels | 24.0 M |
| Sensor type | CMOS, Bayer pattern, 14-bit ADC |
| Sensor size [mm] (crop factor) | 23.5×15.6 (1.5×) |
| ISO range | auto (100–25600; conf.), 50–25600 (1/3 stops) |
| Color and post-processing | |
| Color spaces | sRGB, Adobe RGB |
| Image parameters | contrast, saturation, sharpness (-3 – +3) |
| Creative styles | standard, vivid, neutral, clear, deep, light, portrait, landscape, sunset, night view, autumn leaves, B/W, sepia |
| Picture effects | high-key, high contrast monochrome, pop color, posterization (color; B/W), partial color (red; yellow; blue; green), toy camera, retro photo, soft focus, HDR painting, rich-tone monochrome, miniature, watercolor, illustration |
| Picture parameters | – |
| Gamma settings | – |
| Picture profiles | – |
| Soft skin effect | 3 levels, off |
| White balance | auto, daylight, shade, cloudy, tungsten, fluorescent (4 types), flash, direct entry, custom (3 registers) |
| Color temperature range [K] | 2500–9900 |
| Color temperature increments [K] | 100 |
| Color compensation index [steps] | ± 7 (A/B), ± 7 (G/M) |
| White-balance bracketing [pictures per shot] (steps [mired]) | 3 (10; 20) |
| Noise reduction | long exp. (>1s), high-ISO (2 levels; off), multi-frame |
| D-range optimizer | advanced auto, manual (5 levels) |
| DRO bracketing [pictures per shot] (levels) | 3 (2 levels) |
| Auto HDR | auto, manual (1–6 EV) |
| Lens compensation | vignetting, chromatic aberration, distortion |
| Movie recording | |
| Movie resolutions [size/fps] | 1920×1080p60, 1920×1080p50, 1920×1080p25, 1920×1080p24, 1920×1080i60, 1920×1080i50, 1440×1080p30, 1440×1080p25, 640×480p30, 640×480p25 |
| Movie ISO range | 100–12800 |
| Shutter speed (movie) [s] | 1/4 – 1/8000 |
| Movie formats | XAVC-S, AVCHD 2.0, MPEG-4 |
| Audio formats | Dolby Digital AC3, MPEG4 AAC-LC |
| Movie length | 29 minutes |
| Microphone | built-in (stereo), 3.5 mm plug (stereo), Multi Interface (stereo), level control |
| Audio monitoring | – |
| Movie features | auto slow shutter, picture effects, creative styles, HDMI info off, clean HDMI out |
| Auto-focus | |
| AF sensors | 64 line, 15 cross |
| AF range [EV] | −2 – 18 |
| AF modes | AF-A, AF-S, AF-C, DMF, Tracking AF |
| AF range limiter | yes |
| AF assist light | no |
| AF adjustment [no. of lenses] | 30 |
| AF bracketing [step width] ([number of shots]) | - (-) |
| Features | |
| Eye-start | yes |
| Anti-Shake/Super Steady Shot | yes |
| Remote control via USB/WiFi | yes |
| Other features | pellicle mirror, top LCD, intelligent preview, MF peaking, on-screen help, Anti-Dust, BRAVIA Sync, face recognition, auto object framing, smile shutter, sweep panorama, speaker, level gauge, smart teleconverter, WiFi support, NFC |
| Metering | |
| Metering modes | 1200 segments, center-weighted, spot |
| Metering range [EV] (with spot) | −2 – 17 (−2 – 17) |
| Auto Exposure Lock button | yes |
| Exposure modes | iAuto, iAuto+, P with shift, A, S, M with shift, High-Speed |
| Subject programs | portrait, landscape, closeup, sport, night view, night portrait, hand-held night shot, sunset, 3 preset modes |
| Exposure compensation [stops] (steps [stops]) | ± 5 (1/2), ± 5 (1/3) |
| Zebra | yes |
| Flash | |
| Flash shoe type | Multi Interface |
| Accessory shoe cap | FA-SHC1M |
| Flash modes | normal, red-eye reduction, rear sync, slow sync |
| Flash metering | Pre-Flash TTL, ADI, manual (1/1 – 1/16) |
| Requires D flash unit | yes |
| Flash guide number [m]/ coverage [mm] | 12/unknown |
| X-Sync speed [s] | 1/250 |
| High Speed Sync | yes |
| Wireless flash | yes |
| Wireless x-sync speed [s] | 1/250 |
| Wireless HSS | yes |
| Ratio flash control | yes |
| Flash exposure compensation [stops] (steps [stops]) | ± 3 (1/2), ± 3 (1/3) |
| Studio flash socket | yes |
| Flash Exposure Level lock | yes |
| Viewfinder | |
| Viewfinder type | electronic |
| Viewfinder resolution [pixels] | 1024×768 |
| Viewfinder coverage | 100% |
| Viewfinder magnification | 1.09× |
| Eye relief [mm]/ from frame [mm] | 27.0/22.0 |
| Screens | – |
| Diopter adjustment [diopters] | -4.0 – +3.0 |
| Eyepiece cup | FDA-EP12 |
| Viewfinder accessory compatible | yes |
| Live View | main sensor |
| Live View zoom | 1×, 5.9×, 11.7× |
| AS/SS scale in viewfinder | no |
| Display | |
| Display technology, size [mm/inches], resolution [dots] | TFT, 3″, 1228800 |
| Display mount | tilt up 90°, tilt down 180°, swivel |
| Histogram display | luminance, RGB |
| Automatic brightness | yes |
| Touch screen | no |
| Video output interfaces | HDMI-Micro (1080p/1080i/4K) |
| Display accessories (opt.) | screen protector PCK-LM14 |
| Shooting | |
| Frame rate [fps] | 12, 8, 3 |
| Frame rate with AF [fps] | 12.0 |
| Frame rate with live view [fps] | 12 |
| Shutter speed (still) [s] | 30 – 1/8000, B |
| Shutter type | mech., elec. f. c. |
| Self-timer [s] | 10, 2 |
| Continuous self-timer [shots] | 5, 3 |
| Bracketing frames (stops) | 3, 5 (1/3, 1/2, 2/3), 3 (1, 2, 3) |
| Remote release socket | Multi Terminal, Minolta/Sony 3-pin |
| Wireless remote release | RMT-DSLR1, RMT-DSLR2, RMT-VP1 |
| Release priority | yes |
| Depth of field preview | yes |
| Aperture can be changed during depth of field preview | yes |
| Silent depth of field preview | yes |
| Storage | |
| Storage media (number of slots) | Memory Stick Duo, PRO Duo, PRO-HG Duo, SD, SDHC, SDXC, Eye-Fi (1) |
| Remote storage via USB | no |
| Remote storage via FTP | no |
| File system formats | FAT12, FAT16, FAT32, exFAT |
| File formats | ARW 2.3, JPEG w/ EXIF 2.3 |
| Power | |
| Batteries | 1× NP-FM500H |
| Battery pack | – |
| Vertical grip | VG-C77AM (1×/2× NP-FM500H) |
| External power supply | AC adaptor AC-VQ900AM, AC adaptor AC-PW10AM |
| Construction and accessories | |
| Weather sealing | yes |
| Mount material | steel |
| Weight [g] | 647 |
| Standard accessories | strap, body cap ALC-B55, accessory shoe cap FA-SHC1M, USB cable, battery NP-FM500H, charger BC-VM10, software |
| Other optional accessories | microphone ECM-CG50, microphone ECM-ALST1, microphone ECM-XYST1M |
| Misc | |
| Other interfaces | USB 2.0 (High Speed; Micro-B; Multi Terminal) |
| USB modes | mass storage, MTP |
| Printing | Exif Print, Print Image Matching Ⅲ |
| Latest firmware version (release date) | 2.00 (12/2014) |
| Comments | XAVC-S support requires firmware 2.00 or later |
| Reviews & links | Angela Nicholson on TechRadar (full review), Dan Bracaglia, Rishi Sanyal on DPReview.com (full review), Dave Etchells, Mike Tomkins on Imaging Resource (full review), John Sison (video), Joshua Waller on ePHOTOzine (full review), Julius Motal at The Phoblographer (full review), Kyle Looney on Reviewed.com (full review), Mark Goldstein on Photography Blog (full review), Paul Nuttall on What Digital Camera (full review) |
| Related cameras | |
| Kits |
|
